Forklift Drive Axle

Drive Axle for Forklifts - A lift truck drive axle is a piece of equipment that is elastically affixed to a vehicle framework using a lift mast. The lift mast is connected to the drive axle and can be inclined round the drive axle's axial centerline. This is accomplished by at the very least one tilting cylinder. Frontward bearing parts together with rear bearing parts of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle could be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing components. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented practically parallel to a plane extending from the swiveling axis to the axial centerline.

Forklift units like for instance H45, H35 and H40 that are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably affixed\connected on the vehicle frame. The drive axle is elastically connected to the forklift frame using many bearing tools. The drive axle consists of tubular axle body together with extension arms connected to it and extend backwards. This particular kind of drive axle is elastically affixed to the vehicle frame by back bearing parts on the extension arms together with forward bearing tools located on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle on tis particular unit of lift truck are sustained utilizing the extension arms through the back bearing components on the frame. The forces created by the lift mast and the load being carried are transmitted into the floor or road by the vehicle frame through the front bearing components of the drive axle. It is essential to be certain the components of the drive axle are configured in a firm enough method in order to maintain stability of the forklift truck. The bearing parts could reduce small bumps or road surface irregularities all through travel to a limited extent and provide a bit smoother function.
